Title: How to exit CAD in-place editing

introduction:CAD software is an important tool in the fields of engineering design, architectural drawing, etc., and the In-Place Edit function is often used to quickly modify blocks or external references. However, many users will encounter confusion about exiting in-place editing mode during use. This article will introduce in detail how to exit CAD in-place editing mode and attach recent hot topics as reference.

1. Steps to exit CAD in-place editing

1.Use the command button:In bit editing, the CAD interface usually displays the option of "Save Changes" or "Give Up Changes". Click the "Close In-place Editing" button to exit.

2.Command line input:Enter on the command lineREFCLOSEorBCLOSE, press Enter to confirm, select Save or give up the modification and exit.

3.Right-click menu:Right-click in the In-Location Edit area and select the "Close In-Location Edit" option.

4.shortcut key:Some CAD versions support useCtrl+EnterThe key combination saves and exits directly.

2. Frequently Asked Questions and Solutions

3. References to popular topics across the network in the past 10 days

The following are the recent (as of October 2023) technology and design topics that have been hotly discussed across the Internet, which may be related to CAD users:

4. Summary and Suggestions

Although the operation of exiting CAD in-place editing mode is simple, you need to pay attention to saving and modifying to avoid data loss. For users who use this feature frequently, it is recommended:

1. Memorize common commands such asREFCLOSE;2. Back up files regularly;3. Pay attention to the CAD version update to learn about new features optimizations.

If the problem is still not resolved, you can consult the official documentation or contact technical support. I hope this article can help you complete CAD design work efficiently!
